What Is a VASI? Reading the Glidepath Lights on Final

A VASI, or Visual Approach Slope Indicator, is a system of ground lights beside the runway that shows you whether you’re on the correct path to land. Described in AIM 2-1-2, it uses red and white lights to tell you at a glance if you’re on the glidepath, too high, or too low — usually a 3-degree descent. It turns a guessing game into a glance.

Judging your descent angle by eyeball alone is hard — especially at an unfamiliar field, at night, or over featureless terrain where the runway plays tricks on you. The VASI takes that judgment off your shoulders. Once you learn to read it, you’ll never look at those colored lights the same way again.

touchdown zone" src="https://www.angleofattack.com/wp-content/uploads/2026/07/what-is-a-vasi-featured.jpg" style="margin-bottom: 0;">

What Is a VASI?

A VASI (Visual Approach Slope Indicator) is a system of light units beside the runway that gives an arriving pilot visual glidepath guidance on the approach to land. Per AIM 2-1-2, the lights are visible from several miles out by day and farther by night, and the color you see — red, white, or a combination — tells you immediately whether your descent path is correct. Each unit projects white in the upper part of its beam and red in the lower part, so your height in the beam decides the color.

The most common version is the two-bar VASI, with a near (downwind) set of light bars and a far (upwind) set; you read the relationship between them. Some larger airports use a three-bar VASI, which adds a third bar for a second, higher glidepath aimed at high-cockpit aircraft like airliners — but in a Cessna or Piper, you’ll fly the lower glidepath using the near and middle bars. Either way, the job is identical: keep you on a safe, repeatable descent without eyeballing it.

How Do You Read VASI Lights?

You read a standard two-bar VASI by comparing the color of the near (downwind) bar to the far (upwind) bar. Red over white means you’re on the glidepath. Red over red means you’re too low. White over white means you’re too high. Those three combinations are the whole game, and pilots have memorized them with rhymes for decades — a little ridiculous, which is exactly why they stick under pressure:

• “Red over white, you’re all right.” Near bar red, far bar white — you’re on the correct path. Hold what you’ve got.
• “Red over red, you’re dead.” Both bars red — you’re below the glidepath, dangerously low, and you need to add power and arrest your descent.
• “White over white, you’re high as a kite.” Both bars white — you’re above the glidepath. Reduce power and steepen your descent to get back on.

The full read at a glance:

The logic is worth understanding, not just memorizing. The two bars are aimed so their red-white boundaries sit at slightly different angles, with the far bar’s boundary set a touch higher than the near bar’s. On the correct path your eye threads between them: you’re below the far bar’s boundary, so it shows white, and above the near bar’s, so it shows red. Climb too high and the near bar flips to white (white over white); sink too low and the far bar flips to red (red over red). If you ever blank on the why, hold onto the one that matters most — two reds means you are low and sinking toward obstacles, and that’s the picture that should make you add power right now.

What Glidepath Angle Does a VASI Use?

A standard VASI is set to a glidepath angle of 3 degrees, measured from the runway up to the approaching aircraft. That’s the same nominal angle used by most instrument landing system (ILS) glideslopes and by the PAPI — by design — so the descent picture you learn on a VASI transfers to nearly every other glidepath you’ll fly. A 3-degree path is gentle enough to be comfortable and steep enough to clear normal obstacles.

Some VASIs are set steeper than 3 degrees where terrain or obstructions demand it, and that non-standard angle is published in the Chart Supplement (formerly the Airport/Facility Directory). Don’t assume every VASI is exactly 3 degrees — most are, but check the Chart Supplement for any field where the terrain is rising or the approach feels unusual.

A 3-degree path costs roughly 300 feet of altitude per nautical mile over the ground — somewhere around a 400-to-500-foot-per-minute descent for a typical trainer at normal approach speeds. Rather than chase a number, fly the lights and the airspeed. The VASI gives you the angle; your job is power and pitch to keep red over white all the way down to the flare.

What Is the Difference Between a VASI and a PAPI?

The difference between a VASI and a PAPI is the arrangement of the lights and how you read them. A VASI uses bars of lights at two (or three) different distances and you read near bar versus far bar. A PAPI (Precision Approach Path Indicator) uses a single row of four light units, usually on the left side of the runway, and you read how many are red versus white. Both target the same nominal 3-degree path and both keep you on a safe descent.

On a PAPI, the rule is just as simple: four white means too high, two white and two red means on the glidepath, and four red means too low. The summary line is “all white, high as a kite; all red, you’re dead; red and white, you’re all right.” Each light that flips from white to red as you descend tells you you’re settling toward the path, then through it.

Here’s how the two systems line up:

The underlying idea never changes: white is high, red is low, and the balanced picture in the middle is the one you want. Learn the concept once and you can read either system the first time you see it from the cockpit.

Why Does a VASI Keep You Safe From Obstacles?

A VASI keeps you safe from obstacles because the glidepath it projects is engineered to give you safe obstruction clearance on the approach. Per AIM 2-1-2, it provides that clearance within approximately plus-or-minus 10 degrees of the extended runway centerline and out to about 4 nautical miles from the threshold — as long as you stay on the path or above it. Drop below the glidepath and you trade away that protection.

That’s why “red over red, you’re dead” lands so hard. Below the glidepath you may be descending toward the trees, powerlines, terrain, or buildings the path was built to clear. The lights aren’t just warning you the approach will look ugly — they’re telling you you’re sinking into the very obstacles the glidepath exists to keep you above.

This matters most when your other cues are stripped away. On a dark night, over water, or on a runway ringed by unlit terrain, your eyes will lie to you about your height. The “black hole” approach is the classic case: with no visual references, you feel high when you’re actually low and drifting lower. The VASI cuts through that illusion with hard, honest color.

Treat the VASI as guidance, not a guarantee. It protects the corridor it was built for, but it doesn’t see the airplane that taxied onto the runway or the deer standing on the numbers. Fly the lights, stay on or above the path, and keep your eyes outside.

If you want approach-and-landing skills like this to feel automatic instead of theoretical, our free Total Student Pilot course walks you through reading the runway environment step by step, and the full Private Pilot Ground School takes you all the way through airport operations, the regs, and your written test.

Do You Have to Use the VASI by Regulation?

At a towered airport, yes — there’s a regulation that puts teeth on it. Under 14 CFR § 91.129(e)(3), when approaching to land on a runway served by a visual approach slope indicator at an airport with an operating control tower, you must maintain an altitude at or above the glidepath until a lower altitude is necessary for a safe landing. In plain English: don’t dive below the VASI’s path on a towered approach.

The rule exists because dipping below the glidepath is exactly what flies airplanes into obstacles short of the runway. It doesn’t force a perfectly pegged 3-degree descent — being a touch high (white over white) is legal and often sensible — but it draws a hard line at being below the path.

At a non-towered airport that exact regulation doesn’t apply, but the smart move is identical. The glidepath was engineered for obstruction clearance whether or not a tower is watching. Make “stay on or above the VASI” a personal rule everywhere, and you’ll never be the pilot explaining why you clipped the approach lights.

A Lesson From a Black-Hole Approach in Alaska

Let me tell you about the night the VASI earned my full respect. I was flying a Cessna 172 into a coastal Alaska strip after sunset — the kind of approach where the runway sits past a stretch of black water with almost nothing lit between me and the threshold. Clear air, calm wind, and a textbook setup for the black-hole illusion.

Everything in my gut said I was coming in too high. The runway looked like it was floating up there, and every instinct wanted to pull the power and drop down to “fix” it. If I’d flown the feeling, I’d have descended low across that dark water with zero margin and no reference to catch me.

Then I caught the lights. Red over white. On the glidepath. The exact moment I wanted to dump altitude, the VASI was telling me — calmly, in two colors — that I was right where I belonged. So I held the picture, flew the lights instead of the feeling, and the runway resolved under me right on profile.

That night rewired how I teach approaches. Your eyes are brilliant by day over familiar terrain, and they will flat-out deceive you on a dark night over water. The VASI doesn’t have eyes to fool. I’ve been in aviation education since 2006 and a CFI since 2017, and I tell every student the same thing: when the lights and your gut disagree on final, the lights win.

PLT Study Guide

These are the FAA Learning Statement Codes (PLT codes) tied to the VASI and visual glidepath indicators. If you see questions on this topic on the Private Pilot knowledge test, they’ll map to these codes. The wording below reflects the official FAA learning-statement language.

PLT147 — Recall airport operations: visual glide path indicators.
This is the core code for the VASI. Know that a VASI provides visual glidepath guidance described in AIM 2-1-2, that the standard glidepath is 3 degrees, and that on a two-bar VASI red over white means on path, red over red means too low, and white over white means too high. Know that the PAPI does the same job with a single row of four lights — two red over two white is on path.

PLT141 — Recall airport operations: markings / signs / lighting.
The VASI is one piece of the airport’s visual aid system. For questions in this family, connect the VASI to the rest of the runway environment — threshold markings, edge lighting, approach lighting — and remember the VASI addresses your vertical path to the runway, not your lateral alignment.

PLT148 — Recall airport operations lighting: MALS / ALSF / RCLS / TDZL.
Approach lighting and visual glidepath indicators get grouped together because both guide the final approach. Know the distinction: approach lighting systems (MALSR, ALSF) help you acquire and align with the runway, while the VASI gives you the vertical descent angle. They complement each other on a night or instrument approach.

Note on the original code hint: the hint provided PLT145 (“Recall airport operations: runway lighting”), which covers runway edge and surface lighting rather than visual glidepath guidance. It does not match this topic and is not used here. The correct primary code for a VASI is PLT147.

Frequently Asked Questions

FROM CHRIS

The VASI feels like trivia until the night it keeps you off the trees. Learn the colors cold — red over white, you’re all right — and learn to trust them over your own eyes when the two disagree on final. Do that, and a dark or unfamiliar approach stops being a white-knuckle event and becomes the steady, repeatable thing a good landing is supposed to be.

Throttle On!

Chris Palmer

Founder & Chief CFI, Angle of Attack — Two-Time Master Aviation Educator and Gold Seal CFI
